10/100M 5 ports poe switch for cctv project Ethernet Switch wholesale
This is a Layer 2 + Optical Ethernet switch with 5*10/100 Mbps RJ45 ports.
It is designed to meet the various application needs, and provide an Ethernet network
communication solution with a high performance-price ratio.
It is high availability and reliability, as well as the rich security features, makes it ideal for
secure data transmission.for connecting with devices like computer, switch, hub, server, etc.
Features
Ø 5 port 10/100Mbps with Auto Uplink™
Ø Automatic MAC address learning and aging
Ø 10/100 Mbps Auto-negotiation , auto-MDI-MDI-X
Ø LED indicators for monitoring power/link/activity
Ø Supports10/100 Mbps-Full/Half-duplex
Ø Excellent heat elimination without cooling fan.
Ø Apply to Urban Intelligent Traffic Monitoring System (ITS), Safe City.
Ø Support dual power redundancy(optional)
Ø The built-in 12V lead acid battery charging circuit. (optional)
![10/100M 5 Ports Poe Switch Ethernet Network Switch For CCTV Project]()
Technical parameter list
| Product Name | 6-port 10/100 Mbps |
| Product Model | OFS-DT6 |
| Network Protocols | IEEE802.3 10BASE-T; IEEE802.3i 100Base-T;IEEE802.3u;100Base-TX/FX;IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x; |
| Fiber port | LC,SC,ST,FC Optional |
| Network Media | 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter)
1000BASE-TX: Cat6 or later UTP(≤100 meter) |
| Fiber Media | Multi-mode:550M- 2KM
Single-mode: 20/40/60/80/100/120KM |
| Performance Specification | Bandwidth: 20Gbps
Packet Forwarding Rate:1488000pps/port
MAC Address Table:4K |
| Forwarding Mode | Store-and-Forward |
| LED Indicators | Power: PWR;FX Link/Act;TP 1000(1-8);
TP Link/Act(1-8) |
| Power Supply | Input: AC100 ~ 250V,
Output:DC12~15V. |
| Max power | 7W |
| Environment temperature | 0 ~ +55℃ |
| Storage temperature | -20 ~ +70℃ |
| Humidity | 5% ~ 90% |
Packaging & Shipping
Packaging & Shipping
What kind of packaging and shipping do you provide?
Professional Packaging
Fast & Safety Shipping——Worldwide
Standard Export carton
Company Information
Shenzhen Optfocus Technology Co.,Ltd was established in 2009, which is a
High -tech enterprise, professional R & D, production and sales of Fiber to the
Home (FTTH), Fiber to the Building (FTTB) & FTTx,
Fiber access network equipment and terminal equipment & cabling system products.
It is committed to provide Customized OEM & ODM services to Global communication
distributors, Telecom Operators and System Integrators.
